AERIAL RESCUE PUMPS

SF05DHV. Prototype Aerial Rescue Pump in Hamilton Yard.    Photo by Alan Forbes.

SF05DHV. Prototype Aerial Rescue Pump in Hamilton Yard.     Photo by Alan Forbes.

SF05DHV Off side lockers. Polmadie Yard.                                                                    9/8/2005.

SF05DHV Front Off side locker showing detachable Jack bar for 12m ladder.                9/8/2005.

SF05DHV Near side lockers. Polmadie Yard.                                                                9/8/2005.

SF05DHV Cage and Pump. Polmadie Yard                 9/8/2005.

SF05DHV Pump locker showing the Godiva triple pressure World Series pump.             9/8/2005.

SF05DHV Platform getting to work and fully extended. The Lacon ladder(12m) comes out automatically when the platform moves off it's housing.

SF05DHV The Lacon ladder out from the body where it is taken down on the beam gantry with the aid of the pole.

SF05DHV Booms extending horizontally to go over the wall. Polmadie Yard.                 9/8/2005.

SF05DHV Cage going down over the wall. Polmadie Yard.                                            9/8/2005.

SF05DHV Booms extended and cage over the wall. Polmadie Yard.                             9/8/2005.

The wireless control box which can control all functions from the ground.

SF05DHV getting to work as a "Safe working platform" on the roof. Polmadie Yard.      9/8/2005.

Thanks to Red Watch Polmadie for allowing me photograph the ARP during their training.

SF06GCV Scania P310 CP14 6x2 RS/JDC/Vema 28M   Clydebank  100_5795        30/9/2006

SF07EKJ Scania P310 CP14 6x2 RS/JDC/Vema 28M CCTV camera in front of OIC and above front of door. 100_8270  17/4/2007
